Titanium Steel Clad Plate is a composite material consisting of a titanium layer bonded to a steel layer. These sheets offer excellent corrosion resistance, strength and durability, making them ideal for a variety of industrial applications.
At NBSM, we provide the best titanium steel clad plates. Our products are customizable, and we can provide satisfactory product solutions according to your needs and industry.
Base Material :
SteelClad Material :
Titanium and Titanium AlloyBase Thickness :
from 8mm to 400mmClad Thickness :
from 2mm to 16mmClad Plate Total Width :
up to 4200mmClad Plate Total Length :
up to 14300mmCustom Titanium Steel Clad Plate for Industrial Use
Titanium Steel Clad Plate
are ideal for use in harsh environments due to their excellent corrosion resistance. This combination creates a material with superior strength and durability, making it suitable for heavy-duty applications.
Corrosion Resistance: Titanium steel clad plate are highly resistant to corrosion, making them ideal for harsh environments.
High Strength: They use a combination of titanium and steel, which provides excellent strength and durability. This makes them ideal for heavy-duty applications.
Cost-effective: Compared to pure titanium products, titanium steel clad plates are more affordable.
Customizable: Titanium steel clad plates can be customized for specific industrial applications.
Ductility: Titanium steel clad plates are ductile. Even when stretched, they will not break or deform, making them versatile.
Applicable Materials for Titanium Steel Clad Plates
Titanium steel clad plates shall comply with industry standards. The composite and parent materials listed in the table can be combined as needed.
| Product Name | Titanium Steel Clad Plate |
| Standard | ASTM B265 |
| Cladding Technique | Explosive welding |
| Cladding Material |
Titanium (TA1, TA2, TA3, TA9, TA10 etc ) ASTM B265 Titanium (Gr1, Gr2, Gr3, Gr7, Gr12 etc ) |
|
Base Metal (various carbon steels) |
ASTM A516, ASTM A515, ASTM A266, ASTM A572, ASTM A709, ASTM A387, ASTM A240, etc. |
| Cladding Sizes | Thickness: Around 0.3mm-60mm Width: Around 400mm-3000mm Length: Around 1000mm-4000mm (negotiation, customizable) |
| Clad Plate Total Thickness | Around 8-120mm |
| Clad Plate Total Width | Around 3600mm or Customizable |
| Clad Plate Total Length | Around 12000mm or Customizable |
| Surface Treatment | Polished, blast cleaned, pickled and passivated as per the applicable standard, or Negotiable. |
| Industrials | Oil & Gas, Petroleum refining, Chemical industry, Electric power, Military, Nuclear energy, Marine etc. |
| Application | Pressure Vessel, Reactor, Tower, Chilling unit, Pre-heater, Pump vessel, Heat-exchanger, Crystalizer Digester, Hydrocracker, Polymerizers, Shift Reactors. |
Contact our material specialists today to discuss your requirements, request a quote, or get technical specifications for your project.
