High-Strength Lightweight Titanium Alloy Plate

High-Strength Lightweight Titanium Alloy Plate

Name: High-Strength Lightweight Titanium Alloy Plate
Availability: InStock

Titanium plate is widely used due to its unique properties such as high strength, light weight, corrosion resistance, biocompatibility and high temperature performance.
Titanium plates are widely used in aerospace, defense, medical, industrial, and oil and gas industries.

Inquire Now

Superior Titanium Alloy Solutions

Our premium titanium alloy sheets are engineered for maximum performance in the most demanding environments. Manufactured to exacting standards, these sheets offer an exceptional strength-to-weight ratio combined with outstanding corrosion resistance.

Lightweight Strength: 45% lighter than steel with comparable strength

Extreme Durability: Exceptional resistance to saltwater, acids, and high temperatures

Material Versatility: Available in multiple grades including Ti-6Al-4V (Grade 5)

Custom Fabrication: Tailored dimensions and surface finishes to meet specific requirements

Ideal for aerospace, medical, marine, and industrial applications where failure is not an option. Our titanium sheets undergo rigorous quality control to ensure they meet international standards including ASTM B265 and AMS 4911.

TA9 Titanium plate

Technical Specifications

Our titanium alloy sheets are produced using state-of-the-art vacuum arc remelting (VAR) technology followed by precision rolling and heat treatment processes. This ensures uniform grain structure and optimal mechanical properties throughout the material.

Each batch undergoes comprehensive testing including ultrasonic inspection, tensile testing, and chemical analysis. We maintain complete traceability from raw material to finished product.

Certifications: ASTM B265,ASTM F67, ASTM F136

Tolerance: Meets ASME standards.

Operating Temperature: -200°C to +600°C (grade dependent)

Detailed Specifications

Parameter	Grade 1	Grade 2	Grade 5 (Ti-6Al-4V)	Grade 23 (Ti-6Al-4V ELI)
Thickness Range	0.5-100mm	0.5-100 mm	0.5-100 mm	0.5-100 mm
Width Range	500-3600 mm	500-3600 mm	500-3600 mm	500-3600 mm
Tensile Strength	240-370 MPa	345-480 MPa	895-1034 MPa	828-965 MPa
Yield Strength	170-300 MPa	275-380 MPa	825-965 MPa	759-896 MPa
Elongation	24% min	20% min	10% min	12% min
Density	4.51 g/cm³
Industry Applications	Fire wall, driver protection, valve covers, bell housings, driveshaft tunnels, brake backing plates, heat shields, rocker shaft stands, jewelry
