Our clad plates for pressure vessels combine the strength of carbon steel with the corrosion resistance of stainless steel or other alloys. This innovative composite material is the perfect solution for critical applications in the chemical, petrochemical and power generation industries.
Base Material :
SA516 Gr.70, SA285 Gr.C, P355GHClad Material :
304L, 316L, 321, 347, Alloy 625Base Thickness :
from 8mm to 200mmClad Thickness :
from 2mm to 16mmClad Plate Total Width :
up to 4200mmClad Plate Total Length :
up to 14300mmPressure Vessel Clad Plates
- Explosion Bonded Technology
- Custom Material Combinations
- ASME & PED Certified
- Global Supply Capability
Corrosion Resistance: Superior resistance to corrosion, erosion, and high-temperature oxidation ensures extended service life in aggressive environments.
Cost-effective: Reduce material costs by using expensive corrosion-resistant alloys only where needed, while maintaining structural integrity with carbon steel backing
Easy Manufacturing: Excellent weldability and formability characteristics simplify fabrication processes and reduce manufacturing time
Technical Specifications
Advanced composite materials for superior performance in extreme conditions. Clad plates shall comply with industry standards. The composite and parent materials listed in the table can be combined as needed.
| Base Material | SA516 Gr.70, SA285 Gr.C, P355GH |
| Cladding Materials | 304/304L, 316/316L, 321, 347, Alloy 625, Titanium Gr.2 |
| Thickness Range | 8 - 200 mm |
| Width Range | 1500 - 4000 mm or Customizable |
| Length Range | 3000 - 18000 mm or Customizable |
| Bond Strength | ≥ 210 MPa (ASTM A264) |
| Testing | 100% Ultrasonic Testing (ASTM A578), Shear Testing, Bend Testing |
